Professional digital speaker management
FX SERIES
DSP SERIES
DSP SERIES
This unit is a high performance, dual channel, fully automatic feedback suppressor, equipped with 2 analog balanced inputs and 2 analog balanced outputs. Designed for high quality sound reinforcement in medium to large scale professional venues.
DSP SERIES
DSP SERIES
DSP SERIES
This device is a high-performance professional audio processor. Designed with high-quality audio amplification, it provides crossover, EQ, compression, delay, signal generation, matrix mixing and other professional functions.
FX SERIES
FX-220E
DSP 32-bit floating-point, 24-bit AD/DA, 96kHz
Feedback 2 channels, 48 filters total
Frequency 20Hz–20kHz, 1Hz notch, ±10Hz shift
EQ 8-band PEQ, compressor, noise gate
Input 2×XLR, 2×TRS, 40kΩ/20kΩ impedance
Max Input 2Vrms, Max Output 1.6Vrms
SNR 108dB (A-weighted), THD ≤0.014%
Dynamic Range ≥110dB standard
Connectivity USB, RS-485 control ports
Size/Weight 482×44.5×265mm, 2.1kg
FX-220C
DSP 32-bit fixed/floating, 96kHz, 1Hz
Feedback 12 static + 12 dynamic/channel
System delay <2ms, frequency shift ±10Hz
ADC/DAC 24-bit high-resolution chips
Frequency response 20Hz–20kHz (±0.5dB)
Input 2×XLR(f) + 2×TRS(f), max +20dBu
Output 2×XLR(m) + 2×TRS(m), max +20dBu
SNR ≥103dB, THD <0.012%, 1kHz
Power <20W, AC 220V 50Hz, USB RS-485
Size 482×44.4×265mm, Weight 2.1kg
FX-1640AI
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <15ms
Frequency response 20Hz–20kHz standard
Input 4×XLR/TRS balanced, 2×RCA unbal
Input impedance 10kΩ, max +15dBu (Line)
Output 2×XLR, 2×TRS balanced, max +15dBu
Dynamic range 115dB, THD+D <0.02%
Filter HPF, LPF, 10-band PEQ, AFS, AGC
Connectivity RS-485, RS-232, USB Type-B
Size 483×44.5×270mm, Weight 4.6kg
DSP SERIES
D-240M
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <2ms
Frequency 20Hz–20kHz, THD+D <0.003%
SNR 112dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +14dBu
Output 4/6/8×Balanced, 10Ω, max +14dBu
Signal delay 0–500ms adjustable/channel
Filters HPF, LPF, 10-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 483×44.5×265mm, Weight 3.5kg
D-260M
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <2ms
Frequency 20Hz–20kHz, THD+D <0.003%
SNR 112dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +14dBu
Output 4/6/8×Balanced, 10Ω, max +14dBu
Signal delay 0–500ms adjustable/channel
Filters HPF, LPF, 10-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 483×44.5×265mm, Weight 3.5kg
D-360M
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <2ms
Frequency 20Hz–20kHz, THD+D <0.003%
SNR 112dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +14dBu
Output 4/6/8×Balanced, 10Ω, max +14dBu
Signal delay 0–500ms adjustable/channel
Filters HPF, LPF, 10-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 483×44.5×265mm, Weight 3.5kg
D-480M
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <2ms
Frequency 20Hz–20kHz, THD+D <0.003%
SNR 112dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +14dBu
Output 4/6/8×Balanced, 10Ω, max +14dBu
Signal delay 0–500ms adjustable/channel
Filters HPF, LPF, 10-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 483×44.5×265mm, Weight 3.5kg
D-240N
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +18dBu
Output 4/6/8×Balanced, 100Ω, max +18dBu
Signal delay 0–1000ms adjustable/channel
Filters HPF, LPF, 7-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 482×44.5×265mm
D-260N
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +18dBu
Output 4/6/8×Balanced, 100Ω, max +18dBu
Signal delay 0–1000ms adjustable/channel
Filters HPF, LPF, 7-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 482×44.5×265mm
D-360N
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +18dBu
Output 4/6/8×Balanced, 100Ω, max +18dBu
Signal delay 0–1000ms adjustable/channel
Filters HPF, LPF, 7-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 482×44.5×265mm
D-440N
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +18dBu
Output 4/6/8×Balanced, 100Ω, max +18dBu
Signal delay 0–1000ms adjustable/channel
Filters HPF, LPF, 7-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 482×44.5×265mm
D-480N
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 48kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 2/3/4×Balanced, 10kΩ, max +18dBu
Output 4/6/8×Balanced, 100Ω, max +18dBu
Signal delay 0–1000ms adjustable/channel
Filters HPF, LPF, 7-band PEQ, crossover
Functions Compressor, limiter, auto gain, test
Size 482×44.5×265mm
D-360Y
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 96kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 3/4×Balanced, 10kΩ, max +20dBu
Output 6/8×Balanced, 100Ω, max +20dBu
Signal delay 0–1000ms per channel adjustable
Filters HPF, LPF, 10-band PEQ, optional FIR
Functions EQ, crossover, compressor, limiter
Size/Weight 483×45×268mm, 3.5kg
D-480Y
DSP 32-bit fixed/floating, ADC/DAC 24-bit
Sampling rate 96kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD+N<0.003%
SNR 120dB, noise <-93dB, crosstalk <-100dB
Input 3/4×Balanced, 10kΩ, max +20dBu
Output 6/8×Balanced, 100Ω, max +20dBu
Signal delay 0–1000ms per channel adjustable
Filters HPF, LPF, 10-band PEQ, optional FIR
Functions EQ, crossover, compressor, limiter
Size/Weight 483×45×268mm, 3.5kg
D-360YF
High-performance DSP 3in/6out, FIR 256 taps
Applications Hall, conference, bar, stadium, DJ
Functions Crossover, EQ, compressor, limiter
Input 2/3/4×Balanced XLR, 10kΩ, +18dBu max
Output 4/6/8×Balanced XLR, 100Ω, +18dBu max
System delay <1ms, channel delay 0–1000ms
Sampling rate 96kHz, ADC/DAC 24-bit chips
Performance Dynamic range 120dB, THD+N<0.003%
Filters HPF, LPF, 10-band PEQ, optional FIR
Size 482×44.5×265mm standard rack size
D-480YF
High-performance DSP 4in/8out, FIR 256 taps
Applications Hall, conference, bar, stadium, DJ
Functions Crossover, EQ, compressor, limiter
Input 2/3/4×Balanced XLR, 10kΩ, +18dBu max
Output 4/6/8×Balanced XLR, 100Ω, +18dBu max
System delay <1ms, channel delay 0–1000ms
Sampling rate 96kHz, ADC/DAC 24-bit chips
Performance Dynamic range 120dB, THD+N<0.003%
Filters HPF, LPF, 10-band PEQ, optional FIR
Size 482×44.5×265mm standard rack size
D-360YT
Professional DSP 3x6, 32-bit, FIR 512 taps
Sampling rate 96kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD<0.003%
Dynamic range 120dB, noise floor <-93dB
Input 2/3/4×XLR, Output 4/6/8×XLR balanced
Max level 18dBu, channel delay 0–1000ms
EQ 10-band PEQ, HPF, LPF per channel
Functions Compressor, limiter, matrix mix
Signal generator sine, pink noise,white noise
Size/Weight 482×44.5×265mm, 3.5kg
D-480YT
Professional DSP 4x8, 32-bit, FIR 512 taps
Sampling rate 96kHz, system delay <1ms
Frequency 20Hz–20kHz (±0.3dB), THD<0.003%
Dynamic range 120dB, noise floor <-93dB
Input 2/3/4×XLR, Output 4/6/8×XLR balanced
Max level 18dBu, channel delay 0–1000ms
EQ 10-band PEQ, HPF, LPF per channel
Functions Compressor, limiter, matrix mix
Signal generator sine, pink, white noise
Size/Weight 482×44.5×265mm, 3.5kg
